YC6VAs/YC6Vs Overvoltage and Undervoltage Protector
YC6VAs/YC6Vs Overvoltage and Undervoltage Prote...
1. Overload protection
2. Short circuit protection
3. Controlling
4. Used in residential building, non-residential building, energy source industry and infrastructure.
5. According to the type of instantaneous release classified as follows : type B(3-5)ln, type C(5-10)ln, type D(10-20)ln
2. Short circuit protection
3. Controlling
4. Used in residential building, non-residential building, energy source industry and infrastructure.
5. According to the type of instantaneous release classified as follows : type B(3-5)ln, type C(5-10)ln, type D(10-20)ln
Conatct Us
Product Details
General
Voltage and current display relay is a microprocessor-based voltage monitoring device for single-phase AC networks to
protect electrical equipment from surge voltage.The device analyzes the main voltage and displays its current value on a digital indicator.Load is switched by electromagnetic relay.The user can set the current voltage value and delay time through the button. The value is stored in non-volatile memory.Aluminum wires and copper wires can be used for connection.
Application
Voltage and current display relay used in administrative,industrial and residential buildings and has the function of protecting single-phase lines:
●Undervoltageprotection;
·Overvoltageprotection;
●Workingundervoltmetermode;
●Overcurrent proteciton.
| Technical data | YC6VAs | YC6Vs | YC6As | |
| Rated supply voltage | AC 220V | |||
| Operation voltage range | AC80V-400V | AC80V-350V | ||
| Rated frequency | 50Hz/60Hz | |||
| Overyoltage(>U)setting range | 230-300V | |||
| Undervoltage(<U)setting range | 140~220V | |||
| Rated current | 40/63A(subject to prodect label) | SuLje | 1~40/63A | |
| >U and<U trip delay | 0.1~30s | 0.5S | 0.5S(>Atrip delay) | |
| Reset/start delay | 1~500S | 1~600S | 1~600S | |
| Voltage measurement accuracy | 2%(Not exceeding 2%of the overall range) | 1%(Not exceeding 1%of the overall range | ||
| Rated insulation voltage | 400V | |||
| Dutput contact | 1NO | |||
| Electrical life | 10⁵ | |||
| Mechanical life | 10⁶ | |||
| Protection degree | lp20 | |||
| Pollution degree | 3 | |||
| Altitude | ≤2000m | |||
| Operating temperature | -50℃~55℃ | |||
| Humidity | ≤50%at 40%(without condensation) | |||
| Storage temperature -30°℃~70℃ | ||||
| Current specification | 15A | 25A | 32A | 50A | 63A |
| Rated operating current(In,A) | 15 | 25 | 32 | 50 | 63 |
| Maximum operating current Imax(A,within 10min) | 25 | 30 | 40 | 60 | 80 |
| Max.power of load(kW) | 3.6 | 5.5 | 11 | 13.9 |
Wiring diagram
Overall and mounting dimensions(mm)
Write your message here and send it to us
Related Products
-
YCCH6 AC ContactorsTechnical data aramete specification 16 20 25 32 40 63 100 Rated Current In(A AC-7a 6 20 25 32 40 63 100 AC-7b 6 12 18 25 32 Conventional Free Air Thermal Curent lth (A) 16 20 25 32 40 63 100 Rated Insulation Voltage Ui M 500 Rated Voltage Ue (V) 250V(2P)400V(4P) Ambient Temperature 5°C~40°℃ Making and Breaking Capacity (AC-7a) 1.5le Main Contacts 2P 1NO 1NC、2NO、2NC 4P 2NO 2NC、3NO 1NC、4NO、 4NC Controlled power AC-7a 230... -
RT18 Low Voltage FuseRT18-32X RT18-32 RT18L-125 Fuse Link Fuse Holder RT18 Type Assorted FUSe Rated voltage(M) Rated Curren(A) Dimension (mm) A B C D E RT18-32(32X)1P 10×38 380 32 82 78 35 63 18 RT18-32(32X)2P 32 82 78 35 63 36 RT18-32(32X)3P 32 82 78 35 63 54 RT18-63(63X)1P 14×51 63 10... -
YCB9NL-40 RCBO ElectronicGeneral 1. Protection against overload and short-circuit currents 2. Protection against the effects of sinusoidal alternating earth fault currents 3. Protection against indirect contacts and additional protection against direct contacts 4. Protection against fire hazard caused by insulation faults 5. Used in residential building 6. According to the type of instantaneous release classified as follows : type B(3-5)ln, type C(5-10)l... -
HA Water Proof Distribution Box (IP65)General HA Series lighting box is in line with IEC-493-1 standard, attractive and durable, safe and reliable, which is widely used in various places such as factory, mansion, residence, shopping center and so on. Features 1. Panel is the ABS material for the engineering, high strength, never change color, the transparent material is PC. 2. Cover push-type opening and closing Face covering of the distr... -
YCS6-D Surge Protection DeviceTechnical data Rated Operating Voltage Uc(V~) 220V 380V 220V 380V Maximum Continuous Operating Voltage Uc(V~) 275V 385V 275V 385V Voltage Protection Level Up(V~)kV ≤0.7 ≤1.0 ≤1.2 ≤1.5 Nominal Discharge Current In(8/20μs)kA 10 Maximum Discharge Current Imax(8/20μs)kA 10 20 Response Time ns <25 Test Standard IEC61643-1 L/N(mm2)The Cross Section of L/N Line 2.5 PE(mm2)The Cross Section of PE Line 6 Fuse or Switch(A 10A,16A 16A,25A Oper... -
