Off-grid Energy Storage Inverter YCDPO-V
Off-grid Energy Storage Inverter YCDPO-V
YCDPO-V is a dedicated off-grid inverter tailored for independent solar energy systems. It efficiently converts DC from batteries or solar panels into AC, powering appliances in areas without grid access. the input voltage range is 115V, the output AC pure sine wave AC230V 50/60HZ, can drive 1.2~5KW single-phase load.
1. Pure sine wave MPPT solar inverter Bulit-in 50/65A MPPT solar charger
2. Battery equalization function extend lifecycle
3. YCDPO-V series is suitable for off-grid applications
4. Equalization function
Contact Us
Product Details
General
YCDPO-V is a dedicated off-grid inverter tailored for independent solar energy systems. It efficiently converts DC from batteries or solar panels into AC, powering appliances in areas without grid access. the input voltage range is 115V, the output AC pure sine wave AC230V 50/60HZ, can drive 1.2~5KW single-phase load.
Operating conditions
1. Pure sine wave MPPT solar inverter Bulit-in 50/65A MPPT solar charger
2. Battery equalization function extend lifecycle
3. YCDPO-V series is suitable for off-grid applications
4. Equalization function
Type designation
| Product name | Rated power(W) | Battery charging voltage | ||
| YCDPO V | - | 1200 2200 3000 3200 5000 |
- | 12 24 48 |
Technical date
| Model | YCDPO V-1200-12 | YCDPO V-2200-24 | YCDPO V-3200-24 | YCDPO V-5000-48 |
| Rated Power | 1200VA/1200W | 2200VA/2200W | 3200VA/3200W | 5000VA/5000W |
| AC INPUT | ||||
| Nominal Voltage(VAC) | 230VAC | |||
| Selectable Voltage Range | 170-280VAC(For Personal Computers);90-280 VAC(For Home Appliances) | |||
| Frequency Range | 50/60Hz(Auto sensing) | |||
| AC OUTPUT | ||||
| Output voltage(VAC) | 230VAC±5% | |||
| Surge Power | 2000VA | 4000VA | 6000VA | 10000VA |
| Rated Frequency(Hz) | 50/60 | |||
| Efficiency | 93% | |||
| Transfer time | 10ms(For Personal Computers);20ms(For Home Appliances) | |||
| BATTERY | ||||
| Battery Voltage(VDC) | 12 | 24 | 48 | |
| Floating Charge Voltage(VDC) | 13.5 | 27 | 54 | |
| Overcharge Protection(VDC) | 16 | 31 | 33 | 63 |
| SOLAR CHARGER &AC CHARGER | ||||
| Max.PV array open circuit voltage(VDC) | 102 | 102 | 102 | 145 |
| Max.PV array power(W) | 700 | 1400 | 1800 | 3000 |
| MPPT input voltage range@ operating(VDC) |
15-80 | 30-80 | 30-80 | 60-115 |
| Max.solar charging current(A) | 50 | 65 | 60 | |
| Max.AC charging current(A) | 20 | 25 | 60 | |
| Max.charging current(A) | 60 | 70 | 120 | |
| ENVIRONMENT | ||||
| Humidity | 5%to 95%RH (Non-condensing) | |||
| Operating Temperature | -10℃ to 50℃ | |||
| Altitude | (2000m Derating) | |||
| Net Weight(KG) | 4.4 | 5 | 6.5 | 9.7 |
| Dimensions DxWxH(mm) | 103*225*320 | 103*225*330 | 118*285*360 | 100*300*440 |
| COMMUNICATION | ||||
| Interface | Standard:RS232 | |||
| Safety standard | EN/IEC62109-1,EN/IEC62109-2 | |||
Schematic diagram of the product connection
Schematic diagram
