MS-35W, S-35W Power Supply

MS-35W, S-35W Power Supply


Single output mini-size power supply

Summary

single output: power 35W

Input voltage: 180~264VAC 120~370VDC

MS-35W

Single output: power 35W
Input voltage: 180~264VAC 120~370VDC

Technical data

Model Specification	MS-35-5	MS-35-12	MS-35-15	MS-35-24
DC output voltage, current	5V 0~6A	12V 0~3A	15V 0~2.4A	24V 0~1.5A
Wave and noise	60mVp-p	80mVp-p	100mVp-p	100mVp-p
Inlet wire stability	±1%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±0.5%	±0.5%	±0.5%
Efficiency	77%	81%	83%	84%
Adjustable range for DC voltage	±10%	±10%	±10%	±10%
Input voltage range	85~264VAC 120~370VDC 47~63Hz
Impact current	Cold start current 30A/230VAC
Overload protection	105%~150% cut off the output, automtic recovery
Over voltage protection	115%~135% shutdownO/Pvoltage, re-Poweronto recover
Setup, rise, hold up time	300ms, 50ms, 80ms/230VAC at full load
Withstand voltage	I/P-O/P: 1.5kV I/P-FG: 1.5kV O/P-FG: 0.5kV 1minute
Isolation resistance	I/P-O/P I/P-FG O/P-F/G: 500VDC/100MΩ
Working temperature	-10℃~+50℃
Dimension	84 ×58 ×38mm

S-35W

Single output: power 35W
Input voltage: 90~132VAC/180~264VAC by switch

Model Specification	S-35-5	S-35-12	S-35-15	S-35-24
DC output voltage, current	5V 0~7A	12V 0~3A	15V 0~2.4A	24V 0~1.5A
Wave and noise	70mVp-p	100mVp-p	100mVp-p	100mVp-p
Inlet wire stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±0.5%	±0.5%	±0.5%
Efficiency	70%	76%	78%	78%
Adjustable range for DC voltage	±10%	±10%	±10%	±10%
Input voltage range	90~132VAC/180~264VACbyswitch254~370VDC47~63Hz
Impact current	Cold start current 30A/230VAC
Overload protection	105%~150% cut off the output, automtic recovery
Over voltage protection
Setup, rise, hold up time	200ms, 100ms, 30ms/230VAC at full load
Withstand voltage	I/P-O/P: 1.5kV I/P-FG: 1.5kV O/P-FG: 0.5kV 1minute
Isolation resistance	I/P-O/P I/P-FG O/P-F/G: 500VDC/100MΩ
Working temperature	-10℃~+50℃
Dimension	129×98×38mm
