TB17 Item No.     Data Voltage     AC 110~240V DC 12~24V 50/60Hz Contact     Timed SPDTc Operation     Time operation Timing range     24H TB35 Item No.     Data Voltage     AC 110~240V DC 12~24V 50/60Hz Contact     Timed SPDTc Timing range     24H

Technical data Item Data Operation speed 0.1mm to 1m/Sec Action frequency Mechanically: 240 times/minute Electically: 20 times/Minute Insulation resistance 100mΩ above(at 500VDC) Contact resistance Under 20mΩ(initial) Bearing voltage Non-contact end: 1000VAC, 50/60Hz for one minute Current parts and noncurrent parts and end and connect opsition: 2000VAC, 50/60Hz for one minute Vibration Machine: 400m/Sec² (about 40G's) 1.5mm 10 to 55Hz: 1.5mm pairs ...

Style Product name Model Color Action type Remarks               Indicator Φ16       Round Square Rectangle       AD16-XD   AD16-FXD AD16-JXD    White    Green    Red      Yellow   Blue         Indicator light                     R/G/Y/B/W could be with LED     0.5-6mm     &nb...

Type Data Dissipated power (during the impulse) 19 VA Illuminated PB control Max. current 3 mA Operating threshold Min. 85 % of Un Duration of the control order 50 ms to 1 s (200 ms recommended) Response time 50ms Voltage rating(Ue) 1P,2P, 3P, 4P 250V AC Ratedcurrent 16A Frequency 50/60Hz Control voltage(V) AC24V/DC12V, AC48V/DC24V, AC110V/DC48V, AC230V/DC110V Maximum number of operations per minut...

CKJ5 series vacuum AC contactor 1 Applicable scope CKJ5 series vacuum AC contactors (hereinafter referred to as contactors) are mainly used in circuits  with AC 50Hz, rated working voltage up to 1140V, and rated working current up to 630A. They are used for long-distance connection and disconnection of circuits, and can be combined with appropriate thermal overload relays or electronic protectors to form vacuum electromagnetic starters. They are particularly suitable...
